SAE J249 Square Neck Carriage Bolt

SAE J249 Square Neck Carriage Bolt
SAE J249 Square Neck Carriage Bolt SAE J249 Square Neck Carriage Bolt SAE J249 Square Neck Carriage Bolt

Large Image :  SAE J249 Square Neck Carriage Bolt

Product Details:
Place of Origin: CHINA
Brand Name: PM
Certification: ISO
Model Number: M5-M12, 1/4"-1"
Payment & Shipping Terms:
Minimum Order Quantity: 100PCS
Price: USD 0.001-3 PER PCS
Packaging Details: 25kgs/carton and 36 cartons on standard export wooden pallets
Delivery Time: 15-25DAYS PER CONTAINER
Payment Terms: L/C, T/T
Supply Ability: 1000 Tons per Month

SAE J249 Square Neck Carriage Bolt

Material: Carbon Steel Diameter: 5/8"
Length: 90mm Grade: Class 10.9
Surface: Black , Black Oxide Sample: All Sample Free
Standard: ASME/ANSI B 18.2.1, DIN603 Product Name: Grade 12.9 Black Finish M12 Thread Square Neck Coarse Thread Coach Bolt
High Light:

SAE J249 Square Neck Carriage Bolt


90mm grade 8 carriage bolt


5 / 8" Square Neck Carriage Bolt

SAE J249 grade 8(metric 10.9) black finish square neck dome head carriage bolt

Carriage bolts are used to fasten wood to wood, wood to metal and metal to metal. They are a member of the round head bolt family and commonly have a "circular head with a low rounded top surface and flat bearing surface, and an integrally formed square neck under the head." Found on chain link fences and often on patio furniture and swing sets made of wood, carriage bolts are also known as: carriage screws, round head square neck bolts, coach bolts; shaker screen bolts (when fully threaded). Since the head is designed not to turn, they are usually tightened by torquing a nut. However, they can be used with an internally threaded (tapped) hole and tightened by turning the carriage bolt's square neck, if accessible.
Threads are standard right-hand and Unified inch coarse series (UNC, Unified National Coarse). Lengths of 6" and shorter are usually fully threaded; lengths longer than 6" are partially threaded.

SAE J249 Square Neck Carriage Bolt 0


Standard: ASME/ANSI B 18.2.1, DIN603,DIN608
Size: 1/4”-1”, M5-M12
Material: Carbon Steel, Alloy Steel, Stainless Steel, Brass
Grade: ASTM A307Gr.A, Class 4.8, 5.8, 6.8, 8.8, 10.9, 12.9; SAE J429 Gr.2, 5,8; B8,B8M,B8T
Thread: UNC, UNF,UN
Finish: Plain, Zinc Plated(Clear/Blue/Yellow/Black), Black oxide, Nickel, Chrome, H.D.G.


Packaging Details: a. bulk in cartons (<=25kg )+ 36CTN/wood solid Pallet

b. bulk in cartons 9"x9"x5" (<=18kg )+ 48CTN/wood solid Pallet

Supply Ability:1000 tons per month

MinimumOrder:200kgs for each specification


Payment :T/T, L/C , D/A , D/P , Western Union,etc

Market:South&north Amrica/Europe/ etc.
